1400HP Drilling Rig for Sale
1400HP Oilwell 840E Drilling Rig for Sale
Drilling Rig - 1400HP for Sale
Oilwell 840E Drilling Rig for Sale
1400HP Oilwell Land Drilling Rig for Sale
Land Drilling Rig - 1400HP for Sale
Oilwell Land Drilling Rig for Sale
Description :
Hoisting, Rotating & Pipe-Handling Equip : Drawworks : Oilwell 840E powered by (2) 1000HP Amerimax traction motors w/10hp blowers (1400HP) Auxiliary Brake : Elmagco 8350 Eddy Current Hoisting Capacity : 700,000LB SHL 1 3/8” Line Rotary Table : Oilwell A275 271/2" powered by 1000HP Amerimax motor Traveling Block : 500 Ton Oilwell Top Drive : National P500 Swivel included, Tesco 500Ton for additional cost*** Iron Roughneck : Varco ST80 available for added cost*** Hydraulic Catwalk : Slingshot style included Pipe Handling : Rotating Mouse Hole
Power Package : Engines : (3) Detroit MTU 4000 2011 year model Diesel : 18,000 gal Bl-Fuel : On Request Generators : (3) MTU 1225KW SCR System : Ross Hill 1400 3 x 4
BOP Equipment : Annular : Horn H25 11” 5000PSI Single Ram : Horn 11” 5000PSI Double Ram : Horn 11” 5000PSI ( hydraulic bop handler for stack) Accumulator : Koomey 8 station, Type 80, 18 bottles Choke Manifold : Horn 4” 10,000 psi Mud/Gas Separator : 60” Dia x 20ft H Vertical skidded Degasser
Tubulars : Drill Pipe : On request Drill Collars : On request
Mast & Substructure :
Mast Type : Pyramid 142ft Hookload : 1,250,000Lb SHL 6 x 60” sheves 1 3/8” 63” Fast line Racking Capacity : 25,000ft 5"
Substructure Type : Pyramid Box on Box 48ft x 31ft x 28ft Clear Height : 30ft Load Ratings : Rig Walking System : Pad Capacity :
Mud System : Mud Pumps : TBD Fluid Ends/ Delivery System : 5,000# WP PSI Fluid Ends and Delivery System Charging Pumps : (2) Cobra 8x6x14 50HP Process PIT : 1 x ( 200 bbl) Three-Compartment w/ (4) Agitators Suction PIT : 1 X(600 bbl) Three-Compartment w/ (3) Agitators Trip Tank : 85BBL One-Compartment w/ 10HP Agitator Trip Tank Pump : 4x3x13 100HP Shale Shakers : (2) Derrick Dual Super “G” Degasser : Derrick Desander : Derrick 2-10ft Cones Desander Pump : 6 x 8 Centrigugal 100HP Desilter : 18 Cone Brandt NOV Desilter Pump : 6 x 8 Centrigugal 100HP Mud Mixing Pumps : 6 x 8 x 14 100HP Drilling Water : (2) 400 bbl water tanks
Transport : Estimated Loads : Appx 50 Loads
WorldRigs has 1400HP Oilwell 840E Drilling Rig - For Sale
Images
1400HP Drilling Rig for Sale
1400HP Oilwell 840E Drilling Rig for Sale
Drilling Rig - 1400HP for Sale
Oilwell 840E Drilling Rig for Sale
1400HP Oilwell Land Drilling Rig for Sale
Land Drilling Rig - 1400HP for Sale
Oilwell Land Drilling Rig for Sale
1400HP Drilling Rig for Sale
1400HP Oilwell 840E Drilling Rig for Sale
Drilling Rig - 1400HP for Sale
Oilwell 840E Drilling Rig for Sale
1400HP Oilwell Land Drilling Rig for Sale
Land Drilling Rig - 1400HP for Sale
Oilwell Land Drilling Rig for Sale
Description :
Hoisting, Rotating & Pipe-Handling Equip : Drawworks : Oilwell 840E powered by (2) 1000HP Amerimax traction motors w/10hp blowers (1400HP) Auxiliary Brake : Elmagco 8350 Eddy Current Hoisting Capacity : 700,000LB SHL 1 3/8” Line Rotary Table : Oilwell A275 271/2" powered by 1000HP Amerimax motor Traveling Block : 500 Ton Oilwell Top Drive : National P500 Swivel included, Tesco 500Ton for additional cost*** Iron Roughneck : Varco ST80 available for added cost*** Hydraulic Catwalk : Slingshot style included Pipe Handling : Rotating Mouse Hole
Power Package : Engines : (3) Detroit MTU 4000 2011 year model Diesel : 18,000 gal Bl-Fuel : On Request Generators : (3) MTU 1225KW SCR System : Ross Hill 1400 3 x 4
BOP Equipment : Annular : Horn H25 11” 5000PSI Single Ram : Horn 11” 5000PSI Double Ram : Horn 11” 5000PSI ( hydraulic bop handler for stack) Accumulator : Koomey 8 station, Type 80, 18 bottles Choke Manifold : Horn 4” 10,000 psi Mud/Gas Separator : 60” Dia x 20ft H Vertical skidded Degasser
Tubulars : Drill Pipe : On request Drill Collars : On request
Mast & Substructure :
Mast Type : Pyramid 142ft Hookload : 1,250,000Lb SHL 6 x 60” sheves 1 3/8” 63” Fast line Racking Capacity : 25,000ft 5"
Substructure Type : Pyramid Box on Box 48ft x 31ft x 28ft Clear Height : 30ft Load Ratings : Rig Walking System : Pad Capacity :
Mud System : Mud Pumps : TBD Fluid Ends/ Delivery System : 5,000# WP PSI Fluid Ends and Delivery System Charging Pumps : (2) Cobra 8x6x14 50HP Process PIT : 1 x ( 200 bbl) Three-Compartment w/ (4) Agitators Suction PIT : 1 X(600 bbl) Three-Compartment w/ (3) Agitators Trip Tank : 85BBL One-Compartment w/ 10HP Agitator Trip Tank Pump : 4x3x13 100HP Shale Shakers : (2) Derrick Dual Super “G” Degasser : Derrick Desander : Derrick 2-10ft Cones Desander Pump : 6 x 8 Centrigugal 100HP Desilter : 18 Cone Brandt NOV Desilter Pump : 6 x 8 Centrigugal 100HP Mud Mixing Pumps : 6 x 8 x 14 100HP Drilling Water : (2) 400 bbl water tanks
Transport : Estimated Loads : Appx 50 Loads
WorldRigs has 1400HP Oilwell 840E Drilling Rig - For Sale
Images
1400HP Drilling Rig for Sale
1400HP Oilwell 840E Drilling Rig for Sale
Drilling Rig - 1400HP for Sale
Oilwell 840E Drilling Rig for Sale
1400HP Oilwell Land Drilling Rig for Sale
Land Drilling Rig - 1400HP for Sale
Oilwell Land Drilling Rig for Sale
If you are interested in the featured equipment,
please contact us on email or call +65 97768837.
